Dahua LCH86-MC410-B 86"
KES 215,000.00
Features
- Dahua Technology 86" UHD Smart Interactive Whiteboard (DHI-LCH86-MC410-B)
- The 86" Dahua Smart Interactive Whiteboard boasts excellent processing capabilities with its 4-core CPU, 4-core GPU, and 4G RAM 32G storage capacity, thanks to Android 9.0 incorporated in its design.
- This whiteboard, which comes with a high-precision infrared frame with a 2 mm identification diameter and a 4K high-definition DLED module, will provide you with an exceptional experience when writing, controlling, or displaying content.
- Video conferencing, wireless screen sharing, file management, HD display, scan & go, and other functions are included.
- This whiteboard will help you modernise your conference space and make your meetings more productive.
- Dahua DHI-LCH86-MC410-B Key Features
- 4K UHD display that delivers a clear image in sharp, vivid colors.
- Android and Windows can be easily switched between (PC module is required for Windows OS).
- Wireless screen sharing from multiple devices, such as phones, computers, and tablets.
- Built-in office document and media files support.
- The startup apps and signal source are all customizable.
- Wireless and wired network connection.
- Embedded 5-MP camera and microphone.
- Real Writing Experience
- The intelligent whiteboard supports pen-point writing. With its Zero Air Gap technology and low latency, writing on the whiteboard feels natural, similar to the real writing experience.
- Wireless Screen Sharing
- In addition to basic file sharing, the device offers wireless screen sharing, interactive operations between two screens, and reverse transmissions. It also supports screen grouping (multiple transmission), host mode (for overall permission control), real-time transmission of images, videos and audios from the wireless camera of the mobile phone to the device, and split-screen mode that displays up to 9 splits on the same screen.
- Easy to Share
- Enhances the experience of sharing files by scanning a code. It automatically determines the network of the device to readily share the QR code across the extranet and the intranet. QR code encryption and extraction are also featured, providing privacy and data security through the required entry of a 6-digit password for verification.
- Hidden Antenna Design
- The Wi-Fi and hotspot antenna is neatly concealed in the front of the device, ensuring the stability of the signal strength when using a flush mount, and giving the device its simple and sleek appearance.
Description
Dahua DHI-LCH86-MC410-B Technical Specification
Built-in System
Operating System: Android 9.0
CPU: Quad-core A55
RAM: 4 GB
ROM: 32 GB
Function
Operating System of External Module: Windows 7/8/10; Android
WiFi: Dual-band 2.4 G/5 G
Wi-Fi Hotspot: Dual-band 2.4 G/5 G; supports enabling Hotspot and Wi-Fi at the same time
LCD Panel
Panel Dimensions: 86-inch
Backlight: DLED
Aspect Ratio: 16:9
Brightness: 350 cd/m²
Resolution: 3840 (H) × 2160 (V)
Viewing Angle: H: 178°; V: 178°
Lifespan: 50,000 hours
Refresh Rate: 60 Hz
Static Contrast: 1200:1
Dynamic Contrast: 6000:1
Camera
Pixel: 5MP
Auto Control: Auto white balance
Distortion: ≤5%
Max. Resolution: Android: 1920 × 1080@30 fps / OPS: 2560 × 1440@30 fps
Field of View: H: 79°; V: 51°; D: 88°
Device Ports
Light Sensor: 1
Front Button: 1 × power button (right side)
Front Ports: 1 × USB 3.0 (left side)
Network Port: 1 × RJ-45
Wi-Fi: 1 × Wi-Fi; 1 × Hotspot
USB: 3 × USB 3.0; 1 × Micro USB
RS-232: 1 × RS-232
Video Input: 1 × HDMI IN
Audio Output: 1 × 3.5 mm (Line OUT) port
Others: 1 × Touch
IrDA: 1
Touchscreen
Touch Technology Type: Infrared touch technology
Response Time: <10 ms
Touch Points: 20
Valid Touch: 2 mm
Writing Mode: Finger + Pen
Touch Resolution: 32767 × 32767
Speaker
Power: Full frequency: 15 W × 2
Built-in Speaker: 2
Microphone
Pick-up Distance: Far-field sound pickup: 6 m–8 m (19.69 ft–26.25 ft)
Number of Microphones: 2
AGC: YES
Echo Cancellation: YES
Polar Pattern: Omnidirectional
Intelligent Noise Filtering: YES
General
Power Supply: 100–240 VAC, 50/60 Hz
Power Consumption: 400 W
Standby Power Consumption: 0.5 W
Operating Temperature: –10 °C to +45 °C (+14 °F to +113 °F)
Storage Temperature: –20 °C to +55 °C (–4 °F to +131 °F)
Operating Humidity: 10%–90%
Storage Humidity: 10%–90%
Product Material: Metal casing
Glass: Anti-dazzle tempered glass with a hardness of 7 on the Mohs scale
Glass Thickness: 3mm
Casing Color (Frame/Rear): Bottom: Silver; top/left/right: black
Dimensions/Weight
Product Dimensions (with camera): 1,953 mm × 87 mm × 1,205 mm (76.89" × 3.43" × 47.44")
Packaging Dimensions: 2,056 mm × 235 mm × 1,334 mm (80.94" × 9.25" × 52.52")
Net Weight: 64 kg (141.1 lb)
Gross Weight: 77 kg (169.77 lb)
Mounting Hole Dimensions: 750 mm × 400 mm (29.53'' × 15.75'')
What's in the box?
Smart interactive whiteboard: × 1
Power cord: × 3 (EU/US/UK)
Stylus pen: × 2
Quick start guide: × 1
Wall mount bracket (already installed on the whiteboard) : × 1
Accessory package: × 1
Remote control: × 1
